Mobile Solar Security Camera Trailer (SG-009)
$45,198.00
Skip to product information
Mobile Solar Security Camera Trailer (SG-009)
$45,198.00
Hybrid solar-powered surveillance trailer
SG-009 is a hybrid solar-powered surveillance trailer. Three 435 W monocrystalline silicon panels and a built-in DC gasoline generator (up to 2 kW; fixed 1.5 kW charging output) keep the lithium-iron-phosphate battery charged in low-sunlight conditions.
At a Glance
- 3 × 435 W monocrystalline silicon solar panels
- LiFePO4 battery 25.6 V 460 Ah
- MPPT solar controller, 60 A, 99.5% efficiency
- Built-in DC gasoline generator: max 2 kW, fixed charging 1.5 kW
- Telescopic steel mast, max height 7 m, manual lift
- Mobile single-axle trailer (America standard)
Solar System
- Solar panel: monocrystalline silicon
- Rated power: 435 W × 3
- Panel efficiency: 20.3%
Battery System
- Type: lithium iron phosphate
- Capacity: 25.6 V 460 Ah
- Ambient temperature: −30° to 60°
Solar Controller
- Type: MPPT
- Charge current: 60 A (load output and monitoring)
- Efficiency: 99.5%
- Charging time: 8.8 h
- System voltage: DC 24 V
- MPPT controller gateway: TCP 306 RTU-RJ45
- DC output: DC 12 V 240 W, DC 24 V 240 W, DC 48 V 480 W
- AC charge: 1.5 kW AC battery charge; 1× AC charging cable (L = 2 m)
Hybrid System (DC Gasoline Generator)
- Output: DC 25.6 V
- Max power: 2 kW
- Fixed charging power: 1.5 kW
- Fuel: gasoline (regular)
- Nominal fuel capacity: 12 L
- Auxiliary fuel tank: 50 L
- Oil filling: auto
- Start mode: manual, automatic
- Emission: compliant with US environmental emission standards
- Operation temperature: −20° to 60°
Spring Cable
- Network cable: Cat6 × 2
- Power cable: 2× AWG16 + 2× AWG13
- LED power cable: 2× AWG16 (power) + 2× AWG16 (control signal)
Lifting System
- Type: telescopic mast
- Material: mast steel Q235
- Max height: 7 m
- Lift: manual
- Wind rating: 100 km/h
Trailer System
- Type: mobile single-axle trailer
- Standard: America
- Tow hitch: 50 mm ball, 2000 kg
- Stabilization legs: 4 pcs, manual
- Suspension: spring type
- Transport: truck, crane, forklift
- Tyre & rim: 215/75R15
Physical
- Working size: 3430 × 3600 × 7000 mm
- Shipping size: 2150 × 1750 × 2400 mm
- Trailer transport size: 3430 × 1750 × 2400 mm
- Flat transport size: 2400 × 1750 × 2400 mm
- Weight: 1250 kg
Part number: SG-009
