8-Port Multi-Gig PoE Switch

8-Port (2.5G) Layer 2+ Managed PoE Switch with 240 W PoE Budget

Lysora LS2P-8MG2XS-P is an 8-port 2.5G Layer 2+ managed PoE switch. The specification sheet states a 240 W PoE budget (not 125 W) and 2× 10GE SFP+ uplinks.

At a Glance

• 8× 2.5G BASE-T PoE/PoE+ , 240 W budget (from PDF)
• 2× 10GE SFP+
• Switching capacity 80 Gbps; forwarding 59.52 Mpps
• 2× fixed fans; rack/desk

Ports

• Total RJ45 ports: 8
• Optical ports: 2
• 10GE SFP+ ports: 2
• 10/100/1000/2500BASE-T ports: 8

PoE

• PoE/PoE+ out ports: 8
• PoE budget: 240 W
• PoE power pins: 1–2 (+), 3–6 (−)

Hardware

• Switching capacity: 80 Gbps
• Forwarding rate: 59.52 Mpps
• Buffer: 12 Mbit
• CPU: single-core 800 MHz; RAM 512 MB; flash 256 MB
• 2× fixed fans; air cooling, left-to-right

Physical & Power

• Dimensions: 300 × 233 × 43.6 mm
• Weight: 2.64 kg (without packaging)
• Mounting: rack/desk
• Enclosure: metal
• Power: 100–240 V AC, 50/60 Hz
• Max. power consumption: 27 W (no PoE load); 278 W (full PoE)
• Operating temperature: 0°C to +50°C
• Warranty: 3 years

Software

• Layer 2 managed switching (per datasheet title)
• Web / cloud / app management as listed on the Lysora sheet
• PoE watchdog and camera-oriented features where the family sheet lists them
• NDAA compliant (PDF: NDAA Complain)

Part number: LS2P-8MG2XS-P

Downloads

Specification Sheet (PDF)
