Lysora WiFi 7 Tri-Band Ceiling WiFi Access Point (BE14000, Indoor)

L7Pro — Wi-Fi 7 BE14000 tri-band ceiling-mount access point

Lysora L7Pro is a Wi-Fi 7 BE14000 tri-band (2.4 / 5 / 6 GHz) indoor ceiling access point. 2.5GbE copper plus 10GE SFP+. PoE+. Indoor IP41.

At a Glance

• Wi-Fi 7 (802.11be), tri-band; spatial streams: 8
• Coverage 145 m² (ideal)
• Max clients: 128 (2.4 GHz), 256 (5 GHz), 256 (6 GHz), 600 all bands
• 1× 2.5G BASE-T + 1× 10GE SFP+
• Ceiling or wall; mounts included

Wireless

• Standards: IEEE 802.11 a/b/g/n/ac/ax/be
• MIMO: 2.4 GHz 2×2 MU-MIMO; 5 GHz 3×3 MU-MIMO; 6 GHz 3×3 MU-MIMO
• Channel bandwidth: 2.4 GHz 20/40 MHz; 5 GHz 20/40/80/160 MHz; 6 GHz 20/40/80/160/320 MHz
• Wireless data rate: 2.4 GHz 688 Mbps (5/6 GHz rates as on sheet)

Physical & Power

• Dimensions: 220 × 220 × 45 mm (excluding bracket)
• Weight: ≤ 1.1 kg (without packaging)
• Networking: 1× 10/100/1000/2500BASE-T; 1× 10GE SFP+
• Power method: PoE+
• Power consumption: ≤ 30 W
• IP rating: IP41
• Operating temperature: 0°C to 40°C
• Mounting: ceiling, wall (mounts included)

Part number: L7PRO
