Ajax Tag - Contactless Key Tag, Black (100-pack)

Tag — encrypted contactless key fob

Tag and Pass are encrypted contactless access devices for managing the security modes of the Ajax security system. They have the same functions and differ only in their body: Tag is a key fob, and Pass is a card. Pass and Tag only work with KeyPad Plus. This listing is Tag, Black, 100-pack.

At a Glance

• Contactless key fob for arming/disarming at a compatible keypad
• DESFire®, ISO 14443-A (13.56 MHz), 128-bit encryption and copy protection
• Works with or without user binding
• Up to 13 hubs in device memory (bind separately per hub)
• Does not count against the hub device limit

Hub capacity (Tag and Pass)

• Hub Plus: 99
• Hub 2: 50
• Hub Hybrid (2G)/(4G): 50
• Hub 2 Plus: 200

Specs

• Technology: DESFire®
• Operating standard: ISO 14443-A (13.56 MHz)
• Encryption / authentication / protection from signal interception: yes
• Possibility to assign the user: yes
• Maximum number of bound hubs: up to 13
• Compatibility: KeyPad Plus
• Operating temperature: −10°C to +40°C
• Operating humidity: up to 75%
• Overall dimensions (Tag): 45 × 32 × 6 mm
• Weight (Tag): 7 g

Complete set

• Tag — 100-pack (depending on the kit)
• Quick Start Guide

Part number: 42848.90.BL

Downloads

Specification Sheet (PDF)
